VOGEL 527.105S Single Magnetic V-Block 100x70x95 mm – Key-Operated Magnet ≈100 kg – DIN 876/1
(Incl. Tax: €214.72)
Single precision-ground magnetic V-block to DIN 876/1 with key-operated magnet and approx. 100 kg holding force. One 90° V-groove (50 / 19 mm capacity) ensures stable positioning of cylindrical workpieces. Ideal for grinding, measurement and inspection with accuracy better than 10 µm
The single magnetic V-block 100x70x95 mm is designed for precision grinding, dimensional inspection and high-accuracy measurement applications. The contact surfaces are precision ground according to DIN 876/1, ensuring excellent flatness and parallelism with accuracy better than 10 µm—essential for metrology and finishing operations.
The key-operated magnetic system provides an approximate holding force of 100 kg, allowing the V-block to securely hold itself and the workpiece on any flat ferrous surface without external power supply.
This model features one 90° V-groove with capacities 50 mm and 19 mm, enabling accurate centering and reliable support of shafts, tubes and cylindrical components of different diameters.
Thanks to its robust construction and precision machining, this magnetic V-block is suitable for mechanical workshops, inspection rooms and industrial environments where stability, repeatability and reliable positioning are required.
Technical Data – Single Magnetic V-Block 100x70x95 mm
| Specification | Unit | Value |
|---|---|---|
| Code | – | 527.105S |
| Length | mm | 100 |
| Width | mm | 70 |
| Height | mm | 95 |
| V-groove (90°) | mm | 50 / 19 |
| Magnetic holding force | kg | ≈ 100 |
| Accuracy | – | DIN 876/1 < 10 µm |
- Brand:
- VOGEL
- Typology:
- Magnetic V-blocks
- Force :
- 100Kg
