APPLICATION:

Optimised for 5-axis machining.

TYPE:
Mechanical clamping system without power transmitter, manually
operated.
Centric clamping with two mobile jaws.

CUSTOMER BENEFITS:

Ideal jaw guiding characteristics thanks to patented system guide

Very large clamping stroke
Open design for optimised chip flow, allowing easy cleaning, even after
heavy machining
Constant clamping force for every clamping operation and high clamping
Repeatability when using a torque spanner
Optimally suited for use with SKB jaws. These top jaws can safely
clamp blanks and sawn workpieces with a maximum strength of up to 900 N/mm2 at a
depth of cut of 2,5 mm

TECHNICAL FEATURES:
- Basic body made of hardened and ground steel
- Highly positioned clamping jaw
- The upper spindle is located close to the clamping jaws for optimum force transfer
- Long jaw guide and compact design
- Including SKB jaws
- Clamping repeatability 0.02 mm

RZM = RÖHM, central, manual
