4803100 Digital portable wrinklemeter TR-3110 Digitronic series, max. resolution 0.01 μm, parameters Ra, Rz
(Incl. Tax: €1,525.00)
Digital portable roughness tester TR-3110 Digitronic series.
The TR-3110 is a pocket-size roughness tester for the numerical verification of Rz, with direct switching, ideal for on-board application or external verification.
It is certainly the simplest and most economical instrument for measuring roughness, thanks to its advanced microprocessor technology and extremely compact dimensions.
Calibration programme.
Data visualisation on backlit LCD display.
Works in any position, with rechargeable Li-ion batteries.
Integrated probe protection.
Model: TR-3110
Max resolution: 0.01 μm
Readout: Backlit LCD display
Parameters: Ra
Measuring range: Ra 0.05 ÷ 10.0 μm, Rz 0.1 ÷ 50 μm
Measuring unit: μm / μinch
Accuracy: ISO Class 3 compliant
Cut Off: 0.25 / 0.8 / 2.5 mm
Touch probe type: piezoelectric
Feed rate: 1.0 mm/s
Stroke length: 6 mm
Minimum workpiece curvature: Ø 40 mm
Filter: RC analogue
Data output: no
Power supply: Li-ion battery
Dimensions: 110 x 70 x 24 mm
Weight: 200 g
Readout: Backlit LCD display
- Brand:
- RUPAC
- Typology:
- Roughness meter
