PCE Instruments PCE-MPC 20 Portable hygrometer to monitor PM2.5 and PM10 concentrations, with data memory, USB, and measurement of temperature, humidity, and dew point
In stock
SKU
PCE-MPC-20
€811.79
(Incl. Tax: €990.38)
(Incl. Tax: €990.38)
The hygrometer is an essential tool for measuring particles in the air and the content of atmospheric pollutants. It detects particles with a diameter of 0.3, 2.5, and 10 µm, and calculates the mass concentration for PM2.5 and PM10. Thanks to a powerful built-in pump, it ensures an adequate sampling flow. In addition to monitoring air quality, it measures temperature, relative humidity, and dew point. Results are displayed on a screen and can be recorded for future analysis. The battery allows for about 4 hours of mobile use. This device is crucial in potentially harmful environments due to pollution from combustion, energy production, and vehicle emissions.
Technical specifications:
| Mass concentration | |
| Measurable particle sizes | PM2.5 / PM10 |
| Measuring range mass concentration | 0 - 2000 μg / m³ |
| Resolution | 1 μg / m³ |
| Particle counter | |
| Measurable particle sizes | 0.3, 2.5 and 10 μm |
| Flow rate | 2.83 l / min (0.1 ft³) |
| Coincidence error | < 5% at 2,000,000 particles per ft³ |
| Counting efficiency | 50% at 0.3 μm; |
| 100% with particle size > 0.45 μm | |
| Counting modes | Cumulative, differential, concentration |
| Measurement of air temperature and relative humidity | |
| Measuring range air temperature | 0 - 50°C / 32 - 122°F |
| Measuring range dew point temperature | 0 - 50°C / 32 - 122°F |
| Measuring range relative humidity | 0 - 100% |
| Measuring accuracy air temperature | 10 - 40°C / 50 - 104°F: ± 1.0°C / 1.8°F |
| Others: ± 2.0°C / 3.6°F | |
| Measuring accuracy dew point temperature | 10 - 40°C / 50 - 104°F: ± 1.0°C / 1.8°F |
| Others: ± 2.0°C / 3.6°F | |
| Measuring accuracy relative humidity | 0 - 20% rel. Humidity: ± 5% |
| 20 - 80% rel. Humidity: ± 3.5% | |
| 80 - 100% rel. Humidity: ± 5% | |
| Operating conditions | 0 - 50°C / 32 - 122°F, 10 - 90% rel. humidity, |
| Not condensing | |
| Storage conditions | -10 - 60°C / 14 - 140°F, 10 - 90% rel. humidity, |
| Not condensing | |
| Data storage | 5,000 data sets (Micro SD card) |
| Display | 2.8", 320 x 240 pixels |
| Backlit color LCD | |
| Power supply Charger |
Rechargeable battery 1200-mAh, 7.4V 100 - 240 VAC, 50 or 60 Hz |
| Battery Life | About 4 hours in continuous operation |
| Battery recharge time | About 2 hours with AC adapter |
| Dimensions | 240 x 75 x 57 mm / 9.4 x 3 x 2.2 in |
| Weight | 570 g / 1.3 lbs |
The hygrometer is an advanced and sophisticated instrument designed for detecting and measuring the content of particles and pollutants present in the air. This device, essential for monitoring air quality, can measure particles with diameters of 0.3, 2.5, and 10 µm, providing detailed information on the mass concentration for PM2.5 and PM10. Thanks to a powerful built-in pump, the hygrometer ensures optimal sampling flow, guaranteeing precise and reliable measurements even in variable environmental conditions.
Using the hygrometer is extremely simple and intuitive. Once activated, the operator can select the desired measurement modes, and the results are immediately viewable on a clear and detailed display. This backlit display allows for easy reading even in low-light conditions, making the device usable in industrial environments and construction sites where visibility may be limited. The hygrometer features a data memory capable of recording up to 5,000 measurement groups, facilitating data analysis over time. This enables users to monitor variations in air quality and generate detailed reports on environmental conditions.
Another distinctive feature of the hygrometer is its ability to operate both on battery power and through the electrical network. When used in mobile mode, the device offers approximately 4 hours of autonomy, making it extremely versatile for various applications. This portability is particularly useful for professionals working in different environments, as it allows for on-site measurements without the need for a fixed power supply.
The hygrometer is particularly useful in potentially harmful environments for health, such as industrial and urban areas, where air pollution is an increasing problem. The measurements provided can be used to monitor real-time environmental conditions and analyze the impact of human activities on air quality. Major sources of pollution include combustion, energy production, and vehicle emissions, as well as pollution from the construction industry. Monitoring these pollutants is essential to ensure safe and healthy working environments.
An integrated alert function notifies the operator in case of particle values exceeding established limits, ensuring that users can make informed decisions regarding environmental conditions. This feature is crucial for the safety of the working environments, allowing for corrective measures to be taken in real-time.
In addition to measuring temperature, relative humidity, and dew point, the hygrometer is an indispensable tool for engineers, technicians, and professionals engaged in air quality monitoring. The ability to provide data on multiple parameters simultaneously allows for a comprehensive assessment of environmental conditions. With its USB interface, data can be transferred to external devices for further analysis and storage, thus optimizing the environmental management process.
In summary, the hygrometer is an essential device for anyone working in the fields of public health, industrial safety, and environmental monitoring. Its combination of advanced technology, ease of use, and versatility makes it a valuable ally in the fight against air pollution and for the safeguarding of human health.
Caratteristichs:
- Mass concentration PM2.5 / PM10
- Data memory up to 5,000 data sets
- Flow rate 2.83 l / min
- Display with graphic real-time diagram
- Battery or AC operation possible
- Alarm function
- Data memory up to 5,000 data sets
- Flow rate 2.83 l / min
- Display with graphic real-time diagram
- Battery or AC operation possible
- Alarm function
Delivery scope:
1 x Air sampler PCE-MPC 20
1 x Zero filter
1 x Battery
1 x Charger
1 x USB cable
1 x Mini tripod
1 x Hard case
1 x User manual
1 x Zero filter
1 x Battery
1 x Charger
1 x USB cable
1 x Mini tripod
1 x Hard case
1 x User manual
- EAN Code:
- 4250348719270
- Typology:
- Hygrometer
- Brand:
- PCE INSTRUMENTS
- Resolution (mm):
- 1 µg/m³
- Measurements range:
- 0 - 2000 µg/m³
