Threading with tap and die on all types of ferrous and non-ferrous materials, low and high carbon steels, aluminium alloys, brass, bronzes.

All CNC and programmed machine tools such as machining centres, boring machines, CNC milling machines, transfer machines, threading machines, multi-spindle threading machines, lathes, cnc lathes, with different types of attachment.

Through the use of quick-change bushings it is possible to perform all metric threads with taps according to DIN, ISO or other types of threads according to ANSI standards.

Advantages:

Reduced overall dimensions and weight.

Quick change of bushings.

Wide pull and compression stroke to compensate for any errors due to the difference between the machine tool feed and the pitch of tap.

Ball cage that facilitates the use of compensation by improving the thread profile on any material.

Thread depth accuracy ±0.1mm

Ampia corsa a trazione e compressione per compensazione di eventuali errori dovuti alla differenza tra l’avanzamento della macchina utensile e il passo del maschio

Gabbia a sfere che facilita l’uso della compensazione migliorando il profilo del filetto su qualsiasi materiale

Precisione sulla profondità di filettatura ±0.1mm
