Frequency range	30 Hz - 15 KHz
Operating temperature	-10 - +40 °C
Output volume	digitally adjustable (32 levels)
Headphones	32 Ω
Power supply	4 x AAA battery
Battery life	30 h
Dimensions	220 x 35 x 35 mm
Length sensors	70 / 280 mm



The vibrometer is a highly specialized instrument designed to monitor and analyze mechanical vibrations within complex machinery. Thanks to its precision, it is essential for performing preventive maintenance, reducing the risk of sudden and costly failures. The device allows for the detection of noise generated by critical components such as bearings, motors, and other moving parts, which can indicate wear or mechanical anomalies. The vibrometer amplifies these imperceptible sounds, converting them into audible signals that can be easily interpreted by the operator. This enables timely and accurate diagnosis of problems, avoiding more severe damage and prolonged production interruptions.



Using the vibrometer is simple and intuitive, making it accessible even to less experienced technicians. The operator places one of the two interchangeable probes of different lengths directly on the surface of the component to be monitored. The choice of probe varies depending on the accessibility and position of the components to be inspected. Once the probe is positioned, one of the 32 available sound levels can be selected to monitor the noise with unparalleled precision. The sound transmission is amplified, allowing clear perception of vibrations or frictions that indicate impending malfunction.



One of the most relevant aspects of the vibrometer is the inclusion of headphones with noise reduction, providing an optimal user experience even in very noisy industrial environments. These headphones are designed to fit the human ear perfectly, isolating background sounds and allowing the operator to focus exclusively on the vibrations detected by the device. The ergonomics of the headphones and the reduction of ambient noise significantly enhance comfort during prolonged use of the device, thus improving efficiency in monitoring operations.



From a technical standpoint, the vibrometer has a frequency range from 30 Hz to 150 kHz, ensuring broad coverage for a variety of industrial applications. This instrument is particularly useful for monitoring vibrations in industrial sectors, where regular control of rotating machines, bearings, and motors is essential to ensure their proper functioning. The advanced frequency range allows for the detection of vibrations that might go unnoticed with less sensitive tools, offering a higher level of protection for critical machinery.



Thanks to its ergonomic design, the vibrometer is easy to handle even in challenging working conditions. Its compact size and light weight make it ideal for use both in the laboratory and directly in the field. The included case provides effective protection for the instrument during transport, preventing accidental damage and facilitating its use in various operational settings. Additionally, the simplicity of the vibrometer's operation makes it accessible even to operators who need to perform quick measurements without requiring complex setup procedures.



The vibrometer proves particularly effective for preventive maintenance, an approach that allows for intervention on machines before serious failures occur. The noises detected by the instrument are often the first signal of hidden problems, such as frictions or impacts indicating abnormal friction between mechanical components. With early diagnosis, targeted maintenance interventions can be planned, worn parts replaced, and operational continuity ensured without interruptions.



In conclusion, the vibrometer is an indispensable tool for engineers, technicians, and professionals in the field of industrial maintenance. Its ability to detect and amplify noise and vibrations, combined with ease of use and portability, makes it perfect for ensuring the safety and efficiency of machinery. By enabling early identification of potential problems, the vibrometer helps reduce maintenance costs and prevent costly failures, ensuring that industrial machines always operate at optimal levels.



- two different measuring tips
- non-stationary measuring device
- 32 volume levels
- headphones adapted to the human head
- for preventive maintenance and servicing
- noise-suppressing headphones



1 x Vibration Analyzer PCE-S 42,
1 x headphones,
1 x long measuring tip,
1 x short measuring tip,
6 x AAA batteries,
1 x carrying case with shoulder strap,
1 x instruction manual
