Drilling capacity in steel 40 daN/mm2	45mm
Automatic spindle feed	0,06-0,1-0,2mm/1’
Spindle taper	4MT
Quill stroke	130mm
Variable speed	Elettronica
Spindle speed	150÷1.500rpm
Column Ø	140mm
Worktable dimensions	390x505mm
Base dimensions	450x720mm
Min max table/spindle distances	380-840mm
Column/spindle distance	375mm
Three-phase motor (50 Hz – 400V)	1,5/3,0kW
Coolant pump motor power	125W
Dimensions	450x1.120x2.070
Weight	550Kg



Automatic feed
- Quill: The drill is equipped with an automatic quill feed, ensuring precision and consistency during drilling operations.
- Spindle: The spindle feed is also automatic, contributing to greater efficiency and reduced operating time.

LED lighting
- 24V LED lamp: Integrated to provide optimal visibility of the working area, improving precision during drilling operations.

Refrigeration System
- Integrated cooling system in the base frame: Essential for maintaining low temperatures during prolonged operations, preventing tools and workpieces from overheating.



Drilling Capacity
- Steel (40 daN/mm²): The drill is capable of drilling steel up to a maximum diameter of 45mm, demonstrating considerable power and versatility.

Spindle Specifications
- Spindle Shank: 4 CM (Morse taper 4), compatible with a wide range of tools.
- Spindle Stroke: 4 CM, providing suitable drilling depths for various applications.
- Variable Speed: Electronic control allows the spindle speed to be set between 150 and 1,500 revolutions per minute (rpm), adapting to different materials and machining requirements.



Structure and Dimensions
- Column Ø: 140mm, provides stability and strength to the entire structure.
- Workpiece Table Dimensions: 390x505mm, spacious and ideal for supporting workpieces of various sizes.
- Base dimensions: 450x720mm, providing excellent stability and support for the drill.
- Table/Spindle Distance: Min 380mm - Max 840mm, offering a wide range of height adjustment for different types of machining.
- Column/spindle distance: 375mm, sufficient for machining even large workpieces.

Power and Power consumption
- Three-phase motor (50 Hz - 400V): Power of 1.5/3.0 kW, provides the necessary power for the most demanding drilling operations.
- Coolant pump motor: 125W, sufficient to keep the coolant system running efficiently during operations.

Dimensions and Weight
- Overall dimensions: 450x1,120x2,070mm, compact but large enough for complex work.
- Weight: 550kg, ensuring excellent stability in use.
